Factory Lead Time

13 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

SOT-953

Number of Pins

5

Diode Element Material

SILICON

Breakdown Voltage / V

6V

Number of Elements

5

Reverse Stand-off Voltage

6V

Operating Temperature

-40°C~125°C TJ

Packaging

Tape & Reel (TR)

Series

SP1004, SPA®

Published

2009

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

Termination

SMD/SMT

ECCN Code

EAR99

Type

Zener

Terminal Finish

Matte Tin (Sn)

Applications

General Purpose

Additional Feature

LOW CAPACITANCE

Capacitance

5pF

Terminal Position

DUAL

Terminal Form

FLAT

Peak Reflow Temperature (Cel)

250

Time@Peak Reflow Temperature-Max (s)

40

Pin Count

5

Working Voltage

6V

Number of Channels

4

Leakage Current

100nA

Power Line Protection

No

Current - Peak Pulse (10/1000μs)

2A 8/20μs

Voltage - Clamping (Max) @ Ipp

12V Typ

Clamping Voltage

12V

Voltage - Reverse Standoff (Typ)

6V Max

Peak Pulse Current

2A

Max Surge Current

2A

Direction

Bidirectional

Test Current

1mA

Rep Pk Reverse Voltage-Max

6V

Reverse Breakdown Voltage

8V

Height

500μm

Length

1.05mm

Width

850μm

REACH SVHC

No SVHC

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
